GM-compatible 2.625-inch electric fuel level sender with 0–90 ohm output for analog gauges

Description

One Of The Most Necessary Gauges In A Dashboard, Autometer Makes It Easy By Offering 5 Different Resistance Range Configuration To Match Your Existing Fuel Sending Unit. Available In 0-90 Ohm (Gm Mid 60S To Mid 90S), 0-30 Ohm (Early Gm), 73-10 Ohm (Pre 90S Ford And Chrysler), 16-158 Ohm (Later Model Fords) And 240-33 Ohm (Aftermarket Senders Such As The Autometer 3262). Our Patented Air Core Meter Movement Receives Extra Dampening To Help Combat The Effects Fuel Slosh In Non-Baffled Tanks.

• Traditional incandescent lighting illuminates around the perimeter of the dial
• Works with most 1965 to 1997 Chevrolet/GM senders
• 12 and 16 volt compatible, well-suited with nearly every street car or race car electrical system
• Gauge kit includes bulb and socket assembly, red and green bulb covers, mounting hardware, and detailed instructions for installation
• Autometers Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings

Attributes:

• GTIN: 00046074136320
• Brand Name: AutoMeter
• Add-On: 3288;3286;3285;3284;3287

Extended Information:

• Country of Origin: US
• Emissions : CARB Eligible
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 5 x 5.5 x 5.5 inches
• Weight: 0.7 lb
