AEM Intake Air Temperature (IAT) Sensor Kit

Description

Overview

AEM’s Air Inlet Temperature Sensor Kits (AIT) senses the air temperature on the inlet side of the engine.
Air Temp Sensor Kit. 3/8″NPT. Includes: Air Temp Sensor, 3/8″NPT Aluminum Bung, Connector & Pins
Specs

• Accuracy: < 1.5C / 2.7F
• Operating Temp: -40C to 135C / -40F to 275F
• Thermal Time Constant: < 15 sec. The time required for the sensor to achieve 63.2% of its steady state value when subjected to a step change in ambient temperature [Tc=(Tf-Ti)*63.2%+Ti].
• medium: silicone oil
• Sensor Body Material: Brass
• Thread: 3/8″ NPT
• Hex Size: 3/4″
• Installation Torque: 20Nm / 15 ft-lbs
• Weight: 33.3g
• Electrical Termination: Weatherproof connector. Includes Mating Connector, Pins & Wire Seals
• Includes: Air Temp Sensor, 3/8″ NPT Alumium Bung, Mating Connector, Pins & Wire Seals

Features:

• Senses the air temperature on the inlet side of the engine
• Weatherproof connector
• Connector and pins included
